EK-Quantum Torque (Adapter Fitting) – Nickel is a revolvable angled (45°) adapter fitting with G1/4″ threads. In the form of a cut-off cylinder, it is very sturdy and there are zero movements in the revolvable joint. This Quantum Line adapter is made out of CNC machined brass with high-quality Nickel finish while the seal is made by quality rubber O-rings. It is an extremely secure and sturdy piece that will last for many future builds.

The adapter allows for connection of fitting with G1/4″ threads to extend tubing possibilities in your water cooled system allowing for easier bends and better accessibility.



EK-Quantum Torque series products received the prestigious iF Design Award. A robust and industrial aesthetic sets the Torque family apart by highlighting the precise manufacturing processes used to create them. In addition, enthusiasts can add a unique color ring to give a personal accent to the fitting line. The Torque family of fittings offers a secure and modular system of connections between liquid cooling components and tubing within a PC. Quantum Torque series products cover angled adapters, rotary and static extenders, splitters, G1/4″ plugs, drain valves, fittings, and much more.

Technical specifications:
– Material: made of nickel plated brass
– Threads:
* G1/4″ BSP; 4,5mm male thread length
* G1/4″ BSP, 6mm female thread length
– The outer diameter: 23mm
– Installed height: 26mm
– Sealed with high-quality NBR o-ring.

EK-Quantum Torque (Adapter Fitting) – Nickel is a revolvable angled (90°) adapter fitting with G1/4″ threads. In the form of a cylinder, it is very sturdy and there are zero movements in the revolvable joint. This Quantum Line adapter is made out of CNC machined brass with high-quality Nickel finish while the seal is made by quality rubber O-rings. It is an extremely secure and sturdy piece that will last for many future builds.

The adapter allows for connection of fitting with G1/4″ threads to extend tubing possibilities in your water cooled system allowing for easier bends and better accessibility.



EK-Quantum Torque series products received the prestigious iF Design Award. A robust and industrial aesthetic sets the Torque family apart by highlighting the precise manufacturing processes used to create them. In addition, enthusiasts can add a unique color ring to give a personal accent to the fitting line. The Torque family of fittings offers a secure and modular system of connections between liquid cooling components and tubing within a PC. Quantum Torque series products cover angled adapters, rotary and static extenders, splitters, G1/4″ plugs, drain valves, fittings, and much more.

Technical specifications:
– Material: made of nickel plated brass
– Threads:
* G1/4″ BSP; 4,5mm male thread length
* G1/4″ BSP, 6mm female thread length
– The outer diameter: 23mm
– Installed height: 31,5mm
– Sealed with high-quality NBR o-ring.
Note – *** Features, Price, Specifications are subject to change without notice.

EK-Quantum Torque Micro Rotary adapter fittings allow you to make a simple 90° turn in the smallest possible footprint and installation height. With an overall installed height of just 21mm, Torque Micro Rotaries can squeeze into the most difficult places where it would be otherwise impossible to make a bend. This means it is 10mm lower in height than the standard 90° EK-Quantum Torque Rotary angled fitting.

This Quantum Line adapter fitting is CNC-machined from a solid brass bar and protected with Nickel plating. The two parts of the fitting are permanently assembled and sealed with high-quality rubber O-rings.

Since there is no space for conventional knurling, the base of the fitting extends through an opening in the top face where a 6mm Allen key has to be used to secure it in place. Once secured, the body of the fitting is free to rotate in either direction. EK recommends the use of the EK-Loop Multi Allen Key for this application.

A male G1/4” thread is screwed into the desired port, and a fully rotatable joint allows the female G1/4” port to be directed in any perpendicular direction. You can install components in very close proximity thanks to this.

The centreline of the female G1/4″ port is 12.5mm above the mounting surface, the EK-Quantum Torque Micro Rotary 90 rotary angled adapter is compatible with any STC or HDC EK-Quantum Torque fitting and EK-Quantum Torque Micro HDP fittings. The width and overall diameter of the base is 16.5mm.

Technical specification:

– Material: Brass
– Finish: Nickel
– Threads:
* G1/4″ BSP; 4,5mm male thread length
* G1/4″ BSP, 5mm female thread length
– The outer diameter: 16.5mm
– Installed height: 20,75mm
– Sealed with high-quality o-ring
